Kubota KVP30 100200 CRANK CASE COVER Parts Diagram
Exploded-view parts diagram "100200 CRANK CASE COVER" for the Kubota KVP30. 8 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY COVER, C/CA 13943-01063 | 1 | $184.50 | |||
| 010 | COVER,CRANKCASE 13943-01060 | 1 | $184.35 | |||
| 020 | GASKET,CRANK CAS 13921-01180 12506-01180 | 1 | $10.43 | |||
| 030 | BOLT*** 13921-91110 | 1 | $1.36 | |||
| 040 | ASSY GAUGE, OIL 12401-33080 12401-33082 | 1 | $23.89 | |||
| 050 | O-Ring Seal 04811-00180 04816-00180 | 1 | $2.01 | |||
| 060 | Engine Oil Drain Plug 16326-33750 13901-33750 | 1 | $3.52 | |||
| 070 | Packing Gasket 04724-00120 | 1 | $1.07 | |||
Showing 1 to 8 of 8 parts
