Kubota M4500 017000 RADIATOR Parts Diagram
Exploded-view parts diagram "017000 RADIATOR" for the Kubota M4500 and Kubota M4500DT. 29 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 001 | RADIATOR ASSEMBL 15612-72060 Discontinued | 1 | $1,219.21 | |||
| 002 | COCK 14412-73110 15575-73100 | 1 | $27.79 | |||
| 003 | RADIATOR NET*** 15612-72250 Discontinued | 1 | $74.34 | |||
| 004 | Lower Radiator Hose 15612-72850 | 1 | $25.93 | |||
| 005 | Cooling Water Pipe & Front Drive Shaft O-Ring Seal 15108-72873 15108-72870 | 1 | $4.60 | |||
| 006 | Upper Radiator Hose 15612-72940 | 1 | $65.48 | |||
| 008 | FLANGE 15321-72910 15321-72702 | 1 | $173.27 | |||
| 009 | GASKET W/FLANGE 15601-72920 15625-72920 | 1 | $10.74 | |||
| 009 | GASKET, WATER FL 15221-72920 Discontinued | 1 | $5.11 | |||
| 010 | Bolt 01120-50822 01123-50822 | 1 | $1.26 | |||
| 010 | BOLT 01050-50822 01053-50822 | 1 | $1.75 | |||
| 011 | Threaded Stud 01513-00822 01513-50822 | 1 | $1.31 | |||
| 012 | Bolt 01153-50870 | 1 | $3.34 | |||
| 012 | STUD 01513-50870 | 1 | $2.50 | |||
| 013 | Nut 02056-00080 02056-50080 | 1 | $2.34 | |||
| 013 | Nut Fastener 15151-04430 02156-50080 | 1 | $0.60 | |||
| 014 | Spring Washer 04512-50080 | 1 | $0.87 | |||
| 015 | Washer 04011-50080 04012-50080 | 1 | $0.26 | |||
| 016 | PIPE, WATER RETU 15321-73342 15321-73340 | 1 | $12.06 | |||
| 017 | WATERPIPE 15321-73350 | 1 | $8.64 | |||
| 018 | BAND, PIPE 15109-73363 15109-73360 | 1 | $4.60 | |||
| 019 | COVER THERMOSTAT 15601-73260 | 1 | $103.46 | |||
| 020 | Engine Thermostat Gasket 1A021-73270 16221-73270 | 1 | $5.97 | |||
| 021 | Bolt 01023-50835 01123-50835 | 1 | $1.57 | |||
| 021 | STUD 01518-00832 01518-50832 | 1 | $18.78 | |||
| 025 | Engine Coolant Thermostat Assembly 15321-73015 1E401-73012 | 1 | $44.68 | |||
| 027 | Radiator Cap 15101-72030 15272-72020 | 1 | $27.99 | |||
| 028 | PIPE 15601-72710 15701-72710 | 1 | $7.20 | |||
| 029 | SHROUD, FAN 15612-72330 Discontinued | 1 | $100.15 | |||
Showing 1 to 29 of 29 parts
